HD.45
up to 4,5 m.
-
Industrial Use -
Up to 4.5 m. -
Max 500 Kg.
HD.45
Slow reversible hydraulic operator, for gates up to 4,5 m, rear and front joint.
HIGH-PERFORMANCE MOTOR
-
Reliability and high-quality materials
Chrome-plated steel shaft and anodised aluminium profiles ensure maximum resistance to atmospheric agents. Brass bypass valves are used for greater regulation, ensuring maximum crush-resistance. -
Top performances
The electric motor ensures excellent performance, optimal thrust and more intensive use. -
Personalised key-operated release
-
Self-alignment
The rear pivot joint makes installation easier, making up for any lack of alignment of the gate. -
Perfect stroke adjustment
The adjustable front spherical joint enables perfect adjustment of the stroke, the ideal solution for systems on gates that are not perfectly aligned. -
Very easy to install and maintain
The terminal boards built into the oil cap make installation faster and easier. It is also easy to replace the power cable and control the oil level even when the operator is already installed. -
Safe and smooth manoeuvring
The adjustable hydraulic slowdown in the closing phase ensures silent and very smooth manoeuvring. Avoiding strong impacts against the mechanical stops also reduces the risk of breakages.
| No blocks (reversible) | HD.45 |
| Motor supply | 230 Vac 50/60 Hz |
| Max absorbed current | 1,1 A |
| Pump flow rate | 0.75 l/min |
| Absorbed power | 250 W |
| Max. oil pressure | 33 Bar |
| Maximum thrust | 5000 N |
| Capacitor | 10 μF |
| Stroke length | 270 mm |
| Shaft speed | 1 cm/s |
| Ram shaft diameter | 20 mm |
| Hydraulic slow-down | In closing |
| Joints | Front and rear |
| Thermal protection | 150 °C |
| Operating temperature | -20 °C ÷ + 50 °C |
| Protection rating | IP55 |
| Operating cycle | INTENSIVE USE |
| Maximum leaf length | 4.5 m |
| Maximum leaf weight | 500 Kg |
| Oil | D.OIL |
 | BRAINY230 Vac Control Panel. |
 | CIDRA RE-C230 Vac Control Panel. |
 | DREAMY230 Vac Control Panel. |
 | DU.FIXCounterplate suitable for the installation on columns made of stones. |
 | HD.STCInternal mechanical stop in opening and closing. |
 | DU.V9612 Vdc vertical electric lock. |
 | E.LOCK230 Vac vertical electric lock. |
 | E.LOCKSEExtended cylinder for E.LOCK electric lock. |
 | D.OILBiodegradable hydraulic oil. 2-litre container. |
