HD.80
up to 8 m.
-
Industrial Use -
Up to 8 m. -
Max 1000 Kg.
HD.80
Reversible hydraulic operator, for gates up to 8 m. Industrial use.
HIGH-PERFORMANCE MOTOR
-
Innovative technical solutions
The new reversible distributor is made without valves so minimal maintenance is needed to ensure maximum reliability. -
Very intensive use
With the longer reservoir and the new improved electric motor, which is completely submerged in the oil, even more intensive use is possible. -
Self-alignment
The reinforced brackets and front and rear joints make installation easier even when gates are not perfectly aligned. -
Top performance
Fitted with an electric motor that makes it the most powerful in its category, with maximum thrust of 10,000 N. -
Safe and precise manoeuvring
The brass adjustment screws and double-action slowdown mechanism provide very precise manoeuvring and make the system very safe. -
Reliability and high-quality materials
The distributor, header, back plate and piston unit are made from anodised aluminium using a tooling machine, ensuring maximum precision of the components and optimal performance and reliability. -
Very easy to install and maintain
The terminal board makes wiring even easier and lets you swap power cables quickly and easily.
| No blocks (reversible) | HD.80 |
| Motor supply | 230 Vac 50/60 Hz |
| Max absorbed current | 1.3 A |
| Pump flow rate | 0.75 l/min |
| Absorbed power | 310 W |
| Hydraulic slow-down in opening phase | Fixed |
| Hydraulic slow-down in closing phase | Adjustable |
| Max. oil pressure | 50 Bar |
| Maximum thrust | 10000 N |
| Capacitor | 10 μF |
| Stroke length | 390 mm |
| Shaft speed | 0.75 cm/s |
| Ram shaft diameter | 22 mm |
| Joints | Front and rear |
| Thermal protection | 150 °C |
| Operating temperature | -20 °C ÷ + 50 °C |
| Protection rating | IP55 |
| Operating cycle | INTENSIVE USE |
| Maximum leaf length | 8.0 m |
| Maximum leaf weight | 1000 kg |
| Oil | D.OIL |
 | BRAINY230 Vac Control Panel. |
 | CIDRA RE-C230 Vac Control Panel. |
 | DREAMY230 Vac Control Panel. |
 | DU.V9612 Vdc vertical electric lock. |
 | E.LOCK230 Vac vertical electric lock. |
 | E.LOCKSEExtended cylinder for E.LOCK electric lock. |
 | D.OILBiodegradable hydraulic oil. 2-litre container. |
