KFACILE
KFACILE
Application:
1 actuator for roller shutters.
Control unit power supply:
230 Vac - 50 Hz
Motor power supply:
230 Vac (or 115 Vac) 1500W max
Main functions:
Adjustment of parameters and operational logics via dip-switches and button. | Integrated 433.92 MHz triple encoding radio receiver, maximum 64 radio controls. | Adjustable working time. | Fixed terminal boards. | Automatic, semi-automatic or dead man function logic. | Remote transmitter learning logic using “hidden key” function. | Input for step-by-step control and input for safety devices (N.C. contact). | Integrated control button in the box cover. | LED diagnostics with buzzer. | IP54.
 | XSBBox with reduced dimensions for control units and accessories. Protection rating IP54. |
 | T2VATwo-channel transmitter. |
 | THUMB.3232-channel transmitter. |
 | F.BY230-CFlashing light, 230 Vac with built-in aerial. |
