SHADE 4

SHADE 4

Application:​
from 1 to 4 electromechanical motors for blinds and awnings.
Control unit power supply:​
100 - 240 Vac (wide range) 50/60Hz
Motor power supply:​
230 Vac max 300 W per motor
Main functions:​
6 Dip-Switches, 1 switch, 2 trimmers. | LED diagnostics. | Integrated 433.92 MHz 14-code radio receiver and 3 encoding systems (rolling code / programmable code / ARC). | Removable terminal boards. | Motor 1 open/close inputs, motor 2 open/close inputs, motor 3 open/close inputs, motor4 open/close inputs. | Inputs for sun sensor, wind sensor, rain sensor. | Communication Bus for master/slave connection of other 7 SHADE4 control units (total 8 control units to control up to 32 motors). Adjustable working time. | Set-up for X.BE accessory (module for KNX interface). | IP44.
