HD.25
up to 2.5 m.
-
Residential Use -
Commercial Use -
Up to 2.5 m. -
Max 400 Kg.
HD.25
Reversible hydraulic operator for gates up to 2.5 m for multi-flat- residential.
HIGH-PERFORMANCE MOTOR
-
Reliability and high-quality materials
Chrome-plated steel shaft and anodised aluminium profiles ensure maximum resistance to atmospheric agents. Brass bypass valves are used for greater regulation, ensuring maximum crush-resistance. -
Top performances
The electric motor ensures excellent performance, optimal thrust and more intensive use. -
Personalised key-operated release
-
Self-alignment
The rear pivot joint makes installation easier, making up for any lack of alignment of the gate. -
Very easy to install and maintain
The terminal boards built into the oil cap make installation faster and easier. It is also easy to replace the power cable and control the oil level even when the operator is already installed.
| No blocks (reversible) | HD.25 |
| Motor supply | 230 Vac 50/60 Hz |
| Max absorbed current | 1.1 A |
| Pump flow rate | 1 l/min |
| Absorbed power | 250 W |
| Max. oil pressure | 25 Bar |
| Maximum thrust | 4000 N |
| Capacitor | 10 μF |
| Stroke length | 250 mm |
| Shaft speed | 1.3 cm/s |
| Ram shaft diameter | 16 mm |
| Hydraulic slow-down | No |
| Joints | Rear |
| Thermal protection | 150 °C |
| Operating temperature | -15 °C ÷ + 50 °C |
| Protection rating | IP55 |
| Operating cycle | INTENSIVE USE |
| Maximum leaf length | 2.5 m |
| Maximum leaf weight | 400 Kg |
| Oil | HYDRO OIL |
 | BRAINY230 Vac Control Panel. |
 | CIDRA RE-C230 Vac Control Panel. |
 | DREAMY230 Vac Control Panel. |
 | DU.FIXCounterplate suitable for the installation on columns made of stones. |
 | HD.STCInternal mechanical stop in opening and closing. |
 | DU.V9612 Vdc vertical electric lock. |
 | E.LOCK230 Vac vertical electric lock. |
 | E.LOCKSEExtended cylinder for E.LOCK electric lock. |
 | D.OILBiodegradable hydraulic oil. 2-litre container. |
