BRAINY

BRAINY

Application:​
1 or 2 actuators for swing gates, sliding gates closing in opposite directions, hydraulic operators and industrial sectional doors.
Control unit power supply:​
230Vac - 50/60Hz
Motor power supply:​
230Vac 600W + 600W max
Main functions:​
Integrated LCD display. | Integrated 433.92 Hz 64-code radio receiver with 3 encoding systems (programmable code, rolling code, ARC). | Removable terminal boards. | Encoder input to detect obstacles. | Separate limit switch inputs for each motor. | Open, close and pedestrian inputs. | Photocell inputs in opening-closing and in closing phases. | Input for NC or 8k2 sensitive edge. | Output for electric lock 230 Vac and 12 Vac/dc. | Output for open gate indicator, service light, second radio channel and photocell testing. | Autosetting of operating parameters with motors fitted with encoders. | Separate electronic torque adjustment for each motor and working times. | Electronic slow-down system. | Number of cycles. | Programming access password. | Maintenance warning. | IP55.
