UP / UP-C
Dead man control panel.
UP / UP-C
Application:
1 actuator for roller shutters, windows and tilt-opening windows.
Control unit power supply:
230 Vac 1500 W max resistive load
Main functions:
Manned operating logic. | Fixed terminal boards. | Inputs for Open and Close commands in very low safety voltage 12 Vdc. | LED for mains presence. | Available in UP-C version with power cable L = 1.2 m and Schuko two-pole plug. | IP20.
 | T2VATwo-channel transmitter. |
 | THUMB.3232-channel transmitter. |
 | F.BY230-CFlashing light, 230 Vac with built-in aerial. |
