RO.40 5/30
TUBOLAR MOTOR Ø 35MM (5NM - 30 R.P.M)
-
35 mm -
5 Nm
RO.40 5/30
-
Mechanical stop
Adjusting the mechanical stop is easy and intuitive and ensuring a correct stop position in time. -
Robustness and safety
The star-shaped metal reduction gear pin makes the motor very reliable and provides high performances.
| Motor supply | 230 Vac 50 Hz |
| Max absorbed current | 0.5 A |
| Absorbed power | 120 W |
| Limit switch revolutions | 35 |
| Maximum torque | 5 Nm |
| Speed | 30 r.p.m. |
| Operating time | 4 min |
| Protection rating | IP44 |
| 4 x 0.75 mm² cable | lg. 2.5 m |
| Weight | 1.55 kg |
 | RO.40 OT40Ø40 - Octagonal adapters kit. |
 | SHADE230 Vac Control Panel. |
 | SHADE 4230 Vac Control Panel. |
 | ES.MINI230 Vac Control Panel. |
 | RO.4055210 mm flanged square with omega bracket. |
 | RO.OCCEyelet 86 mm, hexagon 7 mm. |
 | RO.OCLEyelet 180 mm, hexagon 7 mm. |
 | RO.ASArticulated bar with hook (L=150 cm). |
 | RO.SD60°Articulated joint with eyelet 60°. |
 | RO.SD90°Articulated joint with eyelet 90°. |
