SB.25AC

up to 2.5 m.

Home Operators for swinging gates | Subway | SB.25AC |

Residential Use
Commercial Use
Up to 2.5 m.
Max 500 Kg.

SB.25AC

Hydraulic actuator for fi tting underground, with built-in hydraulic control unit.
Irreversible with block on opening and closing for gates up to 2.5 m, with hydraulic slowing-down on opening and closing.

HIGH-PERFORMANCE MOTOR

Maximum safety and reliability
The compact single-piece construction is designed for maximum safety. The internal connections reduce the risk of the oil leaking.
Perfect symmetry
The same actuator can be installed on the right or left leafs.
High-quality materials
Made from very high-quality materials. Profiles and headers made from corrosion-proof anodised aluminium, steel cylindrical tubes with Niploy treatment and aluminium cap protecting the metal adjustment valves. Piston unit made entirely of aluminium.
Safe and precise manoeuvring
The brass adjustment screws and double-action slowdown mechanism provide very precise manoeuvring and make the system very safe.
Very easy to install
Installation is easy with the hydraulic control unit assembled in a single piece with the ram. The free-standing foundation block means that the actuator can be replaced without dismantling the gate.

Blocks in opening and closing phases (non-reversible)	SB.25AC
Motor supply	230 Vac 50/60 Hz
Max absorbed current	1,1 A
Pump flow rate	1 l/min
Absorbed power	250 W
Max. oil pressure	30 Bar
Maximum torque	450 Nm
90° opening time (excluding slowing-down)	10 s
Capacitor	10 μF
Angular speed	9 °/s
Hydraulic slow-down	In opening and closing phases
Thermal protection	150 °C
Operating temperature	-20 °C ÷ + 50 °C
Protection rating	IP67
Operating cycle	INTENSIVE USE
Braking rotation angle in closing phase	Fixed 10°
Braking rotation angle in opening phase	Between 80° and 100°
Max usable rotation angle	100°
Maximum leaf length	2.5 m
Maximum leaf weight	500 Kg
Oil	D.OIL
Weight	15 kg

	BRAINY 230 Vac Control Panel.
	CIDRA RE-C 230 Vac Control Panel.
	DREAMY 230 Vac Control Panel.
	SB.KL Release with customised key.
	SB.SL Lever-operated release.
	SB.BUSH Bush with welded plate for reversible models.
	SB.FB Foundation box with cataphoresis coating.
	DU.V96 12 Vdc vertical electric lock.
	E.LOCK 230 Vac vertical electric lock.
	E.LOCKSE Extended cylinder for E.LOCK electric lock.
	D.OIL Biodegradable hydraulic oil. 2-litre container.
