RO.60 85/17

TUBOLAR MOTOR Ø 58MM (85NM - 17 R.P.M)

Home Operators for awnings and blinds | Rolly | RO.60 85/17 |

58 mm
85 Nm

RO.60 85/17

Mechanical stop
Adjusting the stop is easy and intuitive.
Robustness and safety
The star-shaped metal reduction gear pin makes the motor very reliable and high performances.
Mounting without supports
The motor can be mounted without additional supports. Thanks to the metal head, it is very easy and quick to install.

Motor supply	230 Vac 50 Hz
Max absorbed current	1.70 A
Absorbed power	375 W
Limit switch revolutions	25
Maximum torque	85 Nm
Speed	17 r.p.m.
Operating time	4 min
Protection rating	IP44
4 x 0.75 mm² cable	lg. 2.50 m
Weight	5.70 kg

	SHADE 230 Vac Control Panel.
	RO.60 OT70 Ø70 - Octagonal adapters kit.
	SHADE 4 230 Vac Control Panel.
	RO.60 TO70 Round adapters kit.
	ES.MINI 230 Vac Control Panel.
	RO.60 OG78 Ø78 - Ogive adapters kit.
	RO.60 OG85 Ø85 - Ogive adapters kit.
	RO.0551 Pin for 16 mm square with omega bracket.
	RO.0568 100x100 mm plate.
	RO.OCC Eyelet 86 mm, hexagon 7 mm.
	RO.OCL Eyelet 180 mm, hexagon 7 mm.
	RO.AS Articulated bar with hook (L=150 cm).
	RO.SD60° Articulated joint with eyelet 60°.
	RO.SD90° Articulated joint with eyelet 90°.
