RO.60 120/11
TUBOLAR MOTOR Ø 58MM (120NM - 11 R.P.M)
-
58 mm -
120 Nm
RO.60 120/11
-
Mechanical stop
Adjusting the stop is easy and intuitive. -
Robustness and safety
The star-shaped metal reduction gear pin makes the motor very reliable and high performances. -
Mounting without supports
The motor can be mounted without additional supports. Thanks to the metal head, it is very easy and quick to install.
| Motor supply | 230 Vac 50 Hz |
| Max absorbed current | 1.90 A |
| Absorbed power | 415 W |
| Limit switch revolutions | 25 |
| Maximum torque | 120 Nm |
| Speed | 11 r.p.m. |
| Operating time | 4 min |
| Protection rating | IP44 |
| 4 x 0.75 mm² cable | lg. 2.50 m |
| Weight | 5.70 kg |
 | SHADE230 Vac Control Panel. |
 | RO.60 OT70Ø70 - Octagonal adapters kit. |
 | SHADE 4230 Vac Control Panel. |
 | RO.60 TO70Round adapters kit. |
 | ES.MINI230 Vac Control Panel. |
 | RO.60 OG78Ø78 - Ogive adapters kit. |
 | RO.60 OG85Ø85 - Ogive adapters kit. |
 | RO.0551Pin for 16 mm square with omega bracket. |
 | RO.0568100x100 mm plate. |
 | RO.OCCEyelet 86 mm, hexagon 7 mm. |
 | RO.OCLEyelet 180 mm, hexagon 7 mm. |
 | RO.ASArticulated bar with hook (L=150 cm). |
 | RO.SD60°Articulated joint with eyelet 60°. |
 | RO.SD90°Articulated joint with eyelet 90°. |
