SA.24
24 Vdc Control Panel.
SA.24
Application:
1 actuator for roller shutters models SR1.6024 and SR1.6024E, windows and tilt-opening windows.
Control unit power supply:
100/250 Vac – 50/60 Hz
Motor power supply:
24 Vdc 220 W max for 40 seconds
Main functions:
Motor power supply voltage 27.5 Vdc. | Integrated battery charger, compatible with batteries models DA.BT2/DA.BT6. | Removable terminal boards. | IP44.
 | DA.BT22.1Ah 12 Vdc Battery. |
 | DA.BT67Ah 12 Vdc Battery. |
 | T2VATwo-channel transmitter. |
 | THUMB.3232-channel transmitter. |
